With increased resistance to moisture

Wooden pivot with increased resistance to moisture

Roof windows manufactured in pine and vacuum impregnated. Coated with three layers of polyurethane lacquer to form perfectly smooth and durable surface of the window profiles which is homogeneous without a trace of wood grains.



  • A popular design of the windows with a hinge located in the middle of the window height, designed for rooms with higher humidity.
  • Convenient way of using the window as the handle is located at the bottom of the sash. The handle is equipped with a two step micro-opening facilty.
  • Easy cleaning of the outer pane and operating an awning blind with the use of blocking sash bolt when rotated through 180 degrees.
  • Available as standard with energy-saving glazing U3.
  • Increased resistance to burglary - TopSafe system.
  • The thermoPro technology applied ensures improved quality and parameters of roof windows, thus increasing their energy-efficiency performance, providing greater durability, ensuring excellent tightness and facilitating installation process.
  • A wide range of accessories.
  • Wide range of flashings to ensure installation of the window in virtually all types of roof coverings.
  • Possibility to install electrical control.
  • Installation in roof pitches from 15 to 90 degrees.

With increased resistance to moisture



With increased resistance to moisture - FAKROthermoPro technology as standard

System topSafeTopsafe® system of burglary protection as standard





Get inspired

  • FTU-V


    • Air inlet V40Pautomatic air V40P
    • Glazing unit U3U3 - Energy saving double glazed unit:
      Uw=1,3W/m2K with standard flashing,
      Uw=1,2W/m2K with EHV-AT Thermo flashing,
    • Highest quality pine woodhighest quality pine wood, glued in layers, vacuum impregnated
    • Wood painted three times with ecological acrylic lacquerthree coats of polyurethane varnish ideal for creating a durable and smooth finish in white on the surface of the frame
    • Designed for kitchens and bathroomsDesigned for rooms with periodically increased humidity (kitchens, bathrooms)
    • Suitable for pitches from 15-90Installation in roof pitches from 15 to 90 degrees
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
    • 0.97 W/m²K window U-value 0.5 W/m²K glazing U-value 33 dB acoustic insulation Rw 4HT-10-4H-10-4HT glazing unit krypton inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 35dB acoustic insulation Rw 4HS-15-33.1T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle

Instructions and catalogues

 Fitting instructions:

 User manuals:

 ​Film installation instructions

 ​Product details:
