Available colours and fabrics

Awning blinds and roll-up awnings are available in four standard colours (white, grey, black and brown) or any RAL colour on request. The customer also has a choice of fabrics.



  • VMZ, VMB, VML GROUP 10%

    Available in 3 colors (material with 10% relative open area)

Available colours and fabrics



  • VMZ, VMB, VML GROUP 1%

    Available in 2 colors (material with 1% relative open area)

Available colours and fabrics



  • VMZ, VMB, VML GROUP 4%

    Available in 16 colors (material with 4% relative open area)

Available colours and fabrics



  • VMB GRUP 0%


    Available in 20 colors (material with 0% relative open area, transparent)

  • VMZ GRUP 0%

    Available in 4 colors (fabric with 0% relative open area)

Available colours and fabrics



*Cannot be used in VMZ manual.

The colors of the material samples may differ from the real ones.

As a result of temperature changes or after a long period of non-use, the fabric used in VMZ awning blinds may slightly wave. Once unfolded, the fabric should return to its original state.



Colours of VMZ, VMB, VML - Price group I - (fabric with 10% relative open area)

* In awning blinds with fabric 089, where the width exceeds 2100mm, the fabric consists of two parts and is joined together in the middle of the awning (horizontal welded connection).

Colours of VMZ, VMB, VML - Price group II - (fabric with 1% relative open area)

* In awning blinds with fabric featuring 1% relative open area, where the width exceeds 2400mm, the fabric consists of two parts and is joined together in the middle of the awning (horizontal welded connection).

Colours of VMZ, VMB, VML - Price group III - (fabric with 4% relative open area)

*In the case of 4% relative open area, products will come with the fabric consisting of two parts connected in the middle (horizontal welded connection).  In the case of samples 710 – 716, for dimensions close to the maximum size, the fabric can consist of three parts.

Colours of VMB - Price group IV - (fabric with 0% relative open area, transparent)

Colours of VMZ - Price group IV - (fabric with 0% relative open area)

In awning blinds with fabric featuring 0% relative open area, where the width exceeds 1700mm and the height exceeds 1600mm, the fabric consists of two parts and is joined together in the middle of the awning (horizontal welded connection).

*Cannot be used in VMZ manual.

The colors of the material samples may differ from the real ones.

As a result of temperature changes or after a long period of non-use, the fabric used in VMZ awning blinds may slightly wave. Once unfolded, the fabric should return to its original state.

Structure of electrically operated awning blind for vertical windows



The VMZ awning blind is made of durable, weather-resistant fibreglass material coated with PVC. The fabric is rolled up on a spring-loaded shaft with motor and inserted into an aluminium cassette mounted to the window or external lining. There is a special tape in the fabric’s edges that keeps appropriate fabric tension between guide rails and prevents the fabric falling out of them. Such fabric and profile connection increases its resistance against wind and protects insects from getting inside. This solution withstands wind gusts of up to 120 km/h, and side wind speed of up to 220 km/h.

A full blackout fabric can be used in the awning blind.

Electrically operated VMZ Solar awning blind - a solar panel with a light intensity sensor is integrated with the awning cassette.
