Centre pivot

Centre pivot

  • Manufactured in pine, vacuum impregnated and coated with acrylic lacquer.
  • Convenient way to use the window as the handle is located at the bottom of the sash. The handle is equipped with a two step micro-opening facilty.
  • Easy cleaning of the outer pane and operating the awning blind with the use of blocking sash bolt when rotated through 180 degrees.
  • A wide range of accessories. Ability to install electrical controls.
  • Installation in roof pitches from 15 to 90 degrees.

Centre pivot



Convenient way to use the window as the handle is located at the bottom of the sash - FAKROthermoPro technology as standard

System topSafeTopsafe® system of burglary protection as standard

Certyfikat TÜV SÜDCetificate TÜV SÜD





Gallery





  • FTP-V


    • Air inlet V40Pautomatic air V40P
    • Glazing unit U3U3 - Energy saving double glazed unit:
      Uw=1,3W/m2K with standard flashing,
      Uw=1,2W/m2K with EHV-AT Thermo flashing,
    • Glazing unit U5U5 - Energy saving triple glazed unit. Toughened outer pane. U value of window 0.97
    • Glazing unit P2P2 - Laminated and anti-burglary glass:
      Uw=1,3W/m2K with standard flashing,
      Uw=1,2W/m2K with EHV-AT Thermo flashing,
    • Highest quality pine woodHigh quality close-grain vacuum - impregnated redwood pine guaranteed to be knot-free
    • Suitable for pitches from 15-90Suitable for pitches from 15-90°
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals + multi-point opening Elegant handle
    • 0.97 W/m²K window U-value 0.5 W/m²K glazing U-value 33 dB acoustic insulation Rw 4HT-10-4H-10-4HT glazing unit krypton inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals + multi-point opening Elegant handle
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 35dB acoustic insulation Rw 4HS-14-33.1T glazing unit argon inert gas filled panes + external glass toughened automatic V40P air inlet type up to 49m³/h air inlet air flow twice varnishing four seals Elegant handle
    • 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 39dB acoustic insulation Rw 6H-12-33.2SIT glazing unit argon inert gas filled panes + external glass toughened - air inlet type - air inlet air flow twice varnishing four seals + multi-point opening Elegant handle
  • FTS-V


    • Air inlet V22 V22
    • Glazing unit U2 Safety double glazed unit.
    • Highest quality pine woodHigh quality close-grain vacuum - impregnated redwood pine guaranteed to be knot-free
    • Suitable for pitches from 15-90Suitable for pitches from 15-90°
    FTS-V U2
    • 1.3 W/m²K window U-value 1.1 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V22 air inlet type up to 31m³/h air inlet air flow once varnishing two seals + multi-point opening Standard handle
  • FTS


    • Glazing unit U2 Safety double glazed unit
    • Highest quality pine woodHigh quality close-grain vacuum - impregnated redwood pine guaranteed to be knot-free
    • Suitable for pitches from 15-90Suitable for pitches from 15-90°
    FTS U2
    • 1.3 W/m²K window U-value 1.1 W/m²K glazing U-value 32dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened - air inlet type - air inlet air flow once varnishing two seals + multi-point opening Standard handle

Instructions and catalogues

 Fitting instructions:

 User manuals:

 ​Film installation instructions

 ​Product details:
